Short Description:

• Frequency Range: 50Hz-60Hz
• Rated Power-Frequency Withstand Voltage (rms): 3kV AC (1 min)
• Highest voltage for equipment: 0.72kV AC
• Rated short-time thermal current(lth): 60ln
• Rated dynamic current(ldyn): 2.5lth
• Continuous overload: 1.2ln
• Operating temperature: -5°C to 50°C
• Rated security coefficient: 2.5lth
• Standard: IEC61869-1:2007 & IEC61869-2:2012
